| Model | K2 |
| Type | Video Baluns connector |
| Tasks | Used for camera or DVR |
| Dimensions | 13.7 x 11.6 x 3 (mm) |
| Net Weight | 60g |
| Material | ABS Plastic |
| Color | Black |
| MTBF (Expected Reliability) | >10000H |
| Humidity | 0-95 %(non-condensing) |
| Operating Temperature | -10 to 55 Degree C |
| Storage Temperature | -20 to 70 Degree C |
| Transmission Signal | 1 channel |
| Transmission Distance | AHD/CVI: 300m (max.)
TVI: 200m (max.) |
| Supported Network Cables | UTP CAT5/5E/6 |
| Coaxial Video Connector | Push-terminal |
| Compatible Formats | AHD / HDTVI / HDCVI |
| Resolution | 720p / 1080p |
| Anti-interference | > 60dB |
| UTP Cable Connector | 2KV (different-code) |
| Coaxial cable connector | 2KV(common-code) |
| 4KV(common-code) Per | IEC61000-4-5 |
| UTP | 100 Ohms |
| BNC Male | 75 Ohms |
| Transmission Signal | 720P/1080P |
| Transmission Distance | 300 meters for CVI/AHD |
| Power Requirement | Not required for up to 200 meters |
| Surge and Transient Protection | Built-in |
| Other Feature | Super interference rejection |
| Warranty | Not included |
Features of K2 AHD/CVI/TVI 720P/1080P (8MP) Video Balun
Works in Tough Environment
The K2 AHD/CVI/TVI 720P/1080P (8MP) video balun designed to work in the toughest environment. With a wide operating temperature range (-10 to 55 degree C), storing temperature range (-20 to 70 degree C), and humidity tolerance, this device is built to last.
Cable Compatibility
A pair of these baluns work together to transmit the video signal from a CC camera via UTP cables. Compatible UTP cables for these baluns are CAT5, 5e, 6 but we suggest installing category 6 cable for longer distances since they perform slightly better.Â
Lossless Signal Transfer
For cameras and DVRs using AHD/CVI technology, the K2 AHD/CVI/TVI 720P/1080P (8MP) video balun offers lossless signal with up to 300-meter long UTP cable. The length is limited to 200 meters for the TVI technology.
Support for Analog Video Standards
Modern analog video signals such as AHD, HDTVI, HDCVI are supported by the K2 8mp video balun. You can use it to transmit 1080p resolution videos, or 720p videos when you need to save on data space.
Surge and Transient Protection
DVR and cameras can severely damage from high voltages or a sudden spike in the voltage, which may occur during lightning strikes and power fluctuations. The K2 8mp video balun features built-in surge and transient protection to save your equipment in such occasions.Â
K2 AHD/CVI/TVI 720P/1080P (2MP) Video Balun Price in Bangladesh
Buy the K2 8mp Video Balun for 200 Taka from Islamia Computer Technology for your security surveillance setup. If you are looking forward to a bulk purchase, please call +880 1811 422 355 or +880 1973 037 750. We will provide an exclusive price that you can not resist!
